Sensor principle |
Inductive type |
|
Number of safe outputs |
two |
|
Housing diameter |
M12 |
|
Trigger sensing distance Sn |
8 mm 1) |
|
Safe switching distance Sao |
6.5 mm 1) |
|
Safe cutoff distance Sar |
12 mm 1) |
|
Active sensor surface |
one |
|
Manipulation frequency |
≤ 100 Hz |
Safety technical parameters
|
Safety integrity level |
SIL2 (IEC 61508) |
|
category |
Category 2 (ISO 13849-1) |
|
Performance level |
PL d (ISO 13849-1) |
|
PFHD (hazard failure rate per hour) |
6.0 x 10-8 (IEC 61508) 1) |
|
TM (duration of operation) |
20 years (ISO 13849-1) |
|
structural style |
Structural type 3 (ISO 14119-1) |
|
Coding level of excitation element |
Uncoded (EN ISO 14119) |
|
Safer in error situations |
There is at least one safety related semiconductor output terminal (OSSD) in the off state. |
Feature advantage: more secureThe product has passed EN ISO 13849-1:2015 (PL=d, CAT 3), EU CE, North America NRTL, Korea KCs, China CR, SEMI S2, cleanliness class 5 certification, and other certificat……
